Name: UEE924 Non Metal Metallic Glass Plastic Composites Concrete Wood Coating Thickness Gauge
Brand: Testech Group Co., Ltd
SKU: UEE924
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Material: For Metallic And Non-metallic Substrates

Measuring Range: 20μm-1800mm(depends On Probes)

Frequency: 4Hz, 8Hz, 16Hz

Resolution: 0.01inch, 0.001inch,0.0001inch

Probe: Single Crystal/ Dual Crystal

Highlight:

Non Metal coating thickness gauge

UEE924 coating thickness gauge

Wood coating thickness meter

Basic Infomation

Brand Name: TESTECH

Certification: CE, ISO

Model Number: UEE924

Payment & Shipping Terms

Packaging Details: In Carton

Delivery Time: 3-7 days

Payment Terms: T/T, Credit Card, Paypal, Western Union

Supply Ability: 5000pcs/month

Gallery

UEE924 Non Metal Metallic Glass Plastic Composites Concrete Wood Coating Thickness Gauge

Product Description

UEE924 Non-metal/metallic Glass Plastic Composites Concrete Wood Coating Thickness Gauge

It can measure the coating thickness on various metal and non-metal (glass, plastic, composite material, concrete, wood, etc.) substrates and has all the functions of a through coating thickness gauge and a metal coating thickness gauge.

Measuring Materials

Measures coating thickness on metallic and non-metallic substrates (glass, composites, plastics, concrete, wood, etc.)
Suitable for measuring the thickness of metals ( such as steel, cast iron, aluminum, copper, etc. ) , plastics, ceramics, glass, resin, glass fiber and other good conductors of ultrasonic waves.

Technical Parameters

Model	Uee924
Probe Type	Single Crystal/ Dual Crystal
Measuring range	20μm-1800mm(depends on probes)
MeasuringFrequency	4Hz, 8Hz, 16Hz
Pulser	Negative square wave, pulse width and voltage automatically matched to theprobes
Velocity range	400-19999m/s
Automatic shut-down	After 5,10, 20 minutes or Manual
Probe Calibration	One-point, Two-points, Manual
Gain	Auto, manual
Gain Range	0~80dB
Rectification	Full wave, RF, half-wave positive, or half-wave negative
Measurment modes	(1) THIN-EE: Test thin coating mode (2) MB-E : From the start of the emission pulse to the first echo (3) E-E: Thourgh coating, available choose Em– En echo (4) THIN: For testing thin parts
Data mode	Thickness, Differential mode/Reduction rate mode, Min./Max. value mode
A-Scan	Yes
B-Scan	Yes
Coupling state	Yes
Battery indicator	Yes
Language	Chinese/English
Units	mm/inch
Menu operation	Yes
Software function	Dynamic gate setting, blank setting (Blank), echo blank settings (E-Blank), echo freeze, echo pan and zoom in/out
Storage	100,000 thickness measurements (100 groups, 1000 each group) and 500 A-scan, 500 B-scan
Machine upgrade	Available
Display	3.5 inch color screen
Data transfer	By USB port to PC
OperationTemperature	-10℃～＋ 50℃, Special requirements are available up to -20℃
Power supply	3 x AA Li-ion battery (3.7V*3)
Dimensions	184 x 85 x 32 (mm)
Net weight	250 g
Standard accessories	Main machine, probe*1pc, Power adapter, Protect cover, ABS box, Manual, Qualified certificate, Warranty card

UEE924 Non Metal Metallic Glass Plastic Composites Concrete Wood Coating Thickness Gauge 0
