EC-600 China Manufacturer Portable Measuring Instrument Digital Coating Thickness Gauges Meter

EC series thickness gauges can non-destructively measure the thickness of non-conductive coatings on metal surfaces, as well as non-ferromagnetic metal coatings on ferromagnetic metals (such as iron, nickel and cobalt, etc.), specific applications include measuring iron, stainless steel surface paint or galvanizing Layer thickness, measure the thickness of aluminum, copper surface paint or plastic film, etc.

EC-600-P has a built-in magnetic induction and eddy current effect probe, with a measurement range of 0~2000μm and a measurement accuracy of ±(3%+1μm), and its resolution can reach up to 0.1μm.

EC-600-P has only one button, which is very simple to operate. During measurement, the user only needs to quickly attach the probe end to the surface of the object to be measured. During the process of shrinking the probe to the inside of the instrument, the instrument can automatically distinguish the properties of the substrate and measure the thickness of the coating (plating) layer. During the measurement process, the instrument automatically counts and records the measurement results. The recorded data can be transferred to a computer via a USB cable.

EC-600X-P optimizes the principle on the basis of EC-600-P, and uses OLED display to enhance low temperature working performance. Under the condition of using low temperature resistant battery, the extreme working temperature of EC-600X-P can reach -50℃.
