HBRVS-187.5DX Digital Universal Hardness Tester Brinell Rockwell Vickers Touch Screen

1 Piece
MOQ
Bulk discount
Price
HBRVS-187.5DX Digital Universal Hardness Tester Brinell Rockwell Vickers Touch Screen
Features Gallery Product Description Chat Now
Features
Specifications
Warranty: 1 Years
Customized Support: OEM
Place Of Origin: China
Product Name: Hardness Tester Brinell Rockwell Vicker Hardness Testing Machine
Model: HBRVS-187.5DX
Test Force: 5~187.5kgf
Hardness: 0.1HBW
Hardness Resolution: 0.1HR
Data Output: LCD Display,U Disk
Max Height Of Specimen: Rockwell:220mm, Brinell Vickers:170mm
Power: AC220V+5%,50-60Hz
Head - Wall Distance: 200mm
Dimension: 560*260*800mm
Highlight:

Digital brinell rockwell vickers

,

Touch Screen brinell rockwell vickers

,

Universal vickers rockwell brinell
Basic Infomation
Place of Origin: CHINA
Brand Name: TESTECH
Certification: CE; ISO
Model Number: HBRVS-187.5DX
Payment & Shipping Terms
Packaging Details: In Carton
Delivery Time: 3-7 days
Payment Terms: T/T, Credit Card, Paypal, Western Union
Supply Ability: 5000pcs/month
Product Description
HBRV-187.5DX Senior Touch Screen Digital Brinell Rockwell Vickers Universal Hardness Testers Series 5~187.5kgf
Features:
  1. 1. Equipped with three test methods: Brinell, Rockwell and Vickers, and more hardness scales to choose from.
  2. 2. There are 10 types of scales for Brinell and Vickers, and 16 types of Rockwell scales. Scales other than these 36 scales can be customized and changed by users.
  3. 3. Using electronic electric loading, high-precision sensors, and a unique closed-loop control system.
  4. 4. Eyepiece structure with digital encoder to measure D1 and D2 values, and the LCD directly displays the hardness value and D1 and D2 values.
  5. 5. The user interface can input the tester, sample name, measurement results and other information, and save it in the U disk in EXCEL format.
  6. 6. Set password to protect setting parameters, more samples and test information.
  7. 7. Select the hardness scale directly and the force value will automatically change in the test parameters.
  8. 8. The test force is automatically corrected, each force is automatically compensated, and the force accuracy is improved by an order of magnitude.
  9. 9. Calibration can be carried out in two ways: standard hardness block or length scale.
  10. 10. The test force of each level can be automatically corrected through the standard force gauge.
  11. 11. Can convert Brinell, Rockwell and Vickers hardness values.
  12. 12. Touch screen interface, easy to operate.
  13. 13. Automatic hardness conversion according to national standard/ASTM.
Technical Data
Model HBRVS-187.5HDX
Test force 5~187.5kgf
Brinell scale HBW1/5,HBW2.5/62.5,HBW1/10,HBW2.5/15.625,HBW1/30,HBW2.5/31.25,
HBW2.5/62.5,HBW10/100,HBW5/125,HBW2.5/187.5
(select 10 scales)
Hardness resolution 0.1HBW
Rockwell scale HRA,HRB,HRC,HRD,HRF,HRG,HRH,HRK,HRL,HRM,HRP,HRR,HRS,HRV
Hardness resolution 0.1HR
Vickers scale HV5,HV10,HV20,HV30,HV40,HV50,HV60,HV80,HV100,HV120
(select 10 scales)
Hardness resolution 0.1HV
Objective 2.5X,5X(10X,20X optional)
Magnification of microscope Brinell:37.5X, Vickers:75X
Hardness measurement Brinell:8~650HBW Rockwell:20~100HR Vickers:8~2900HV
Data output LCD display,U disk
Max height of specimen Rockwell:220mm, Brinell Vickers:170mm
Head - wall distance 200mm
Dimension 560*260*800mm
Weight About 70Kg
Power AC220V+5%,50-60Hz



Standard Packing List
Item Quantity Item Quantity
Lighting (internal lighting, external lighting) 1 Test block(HRC high,HRC low HRB ,HBW2.5/187.5,HV30) 5
Rockwell,Vickers diamond indenter Each 1 Ball indenter(φ1.5875,2.5,5mm) 3
Eyepiece(DHV-15X) 1 Objective(2.5X,5X) 2
Sliding test table 1 Large, medium, V-test sets Each 1
U memory disk, touch pen Each 1 Fuse 2A 2
Level 1 Regulating screw 4
Power cable 1 Dust bag 1
Certificate, warranty card 1 Manual 1
