High Sensitivity Dual Crystal Straight Probe - Ultrasonic Flaw Detector Sensor for Metal Casting & Forging Defect Detection
Dual-crystal straight probe: Employs a dual-crystal focusing method to enhance defect detection capabilities.
The dual-straight/dual-angle ultrasonic probe series mainly includes: straight probes, angle probes, probes with curvature, focusing probes, surface wave probes, water immersion probes, dual-crystal probes, thickness gauge probes, and high-temperature probes.
Dual-crystal probe: Employs a dual-crystal focusing method to enhance defect detection capabilities. A dual-crystal probe contains two crystals, one as a transmitter and the other as a receiver. Also known as a split probe or combined probe. Applications of dual-crystal probes: Primarily used for detecting defects in welds and plate interlayers.
Applications: Primarily used for detecting defects in welds and plate interlayers.
| Items |
Frequency |
Size of element (mm) |
Focal length (mm) |
Angle |
| Dual Crystal Straight Probe |
2.5-5Mhz |
10×2, 12×2, Φ14×2, Φ20×2 |
F5, F10, F15, F20, F30 |
|
| Dual Crystal Angle Probe |
2.5-5Mhz |
10×12×2, 10×10×2 |
F10, F20, F30 |
45°, 60°, 75°, |
We can manufacture ultrasonic probes of various specifications according to customer requirements.
Our main products include ultrasonic transducers, ultrasonic flaw detectors, connecting cables, high-frequency connectors, piezoelectric crystals, and other testing equipment.
Our company offers a complete range of products: straight probes (hard protective film), straight probes (soft protective film), angle probes, dual-crystal angle probes, surface wave probes, echo probes, dual-crystal straight probes, medical probes, small-angle probes, small-diameter pipe probes, plate wave probes, creeping wave probes, thin plate probes, variable angle probes, rail probes, axle probes, piston probes, dual-crystal bearing probes, brake shoe probes, liquid immersion probes, water-filled probes, dual-crystal water-filled probes, liquid crystal focusing probes, contact focusing probes, contact focusing angle probes, conventional thickness gauge probes, small-diameter pipe thickness gauge probes, medium-temperature thickness gauge probes, high-temperature thickness gauge probes, deep-water probes, and air probes.
Welcome to inquire. Quality guaranteed, discounts available for bulk orders.
